Multi Track Stick Pouch Packing Machine
Model No. | SPT-Stick-600P |
Machine Name | Dairy milk whitener powder stick sachetmultiline track pouch packing machine |
Machine Category | Vertical form, fill and seal multi-track pouch packaging machine |
Filler Type | Advance auger screw filler |
Suitable to Pack | Milk powder, Custard powder, Coffee powder and other similar products |
Filling Range | 1gm to 10 gm |
Speed | As per machine |
No of Track | Customized as per client requirement |
Maximum Roll Width | 600 mm |
Maximum Pouch Height | 200 mm |
Sealing Type | Up to 2400 strokes / hour |
Sealing Temperature | Up to 6 tracks depending on sachet/pouch width |
Sealing Options | Centre seal |
Packing Material | Any heat sealable laminated material |
Film Thickness | Up to 80 Micron |
Film Reel Inner Core Diameter | 76 mm |
Maximum Film Reel Diameter | 400 mm |
Programmable Logic Controller ( PLC ) | Mitsubishi / Inovance |
Switch Gears | Schneider |
Power Supply | 440 Volts, 50 Hz, A.C., Three Phase |
Power Consumption | 10 KW per hour (Approx.) |
Working Temperature | -10 °C to 28 °C (14 °F to 104 °F ) |
Machine Dimension | 3200 x 2600 x 2100 ( L x W x H in mm, Approx.) |
Machine Weight | 1500 Kg. (Approx.) |
Note | Exact specifications may vary and shall be made available upon specific request. |
